Youth elevator basketball stand TCJ-106

1. The base and column are equipped with integrated sponge sheath for indoor and outdoor use.

2. The extension arm of the basketball stand is 1.15m, and the free lifting range of the upper edge of the basket from the ground is 2.1-3.05m.

3. The basketball stand base is 1.50m x 1.00m x 1.00m, and is welded with 60 x 3mm pipes and 5mm thick steel plates.

4. The lower end of the column is a 120×3mm square tube, the upper end of the column is a 100×3mm tube embedded in the 120 tube.

5. The pull rod on the backboard is formed by bending Φ42mm round tube in the automatic pipe bender.

6. Backboard size: 1200×900mm. It adopts high-strength safety and explosion-proof tempered glass,

The outer frame adopts 40mm aluminum profile, and EVA protection bar is installed on the side .

7. The basket: Φ18mm solid round steel, the inner diameter of the ring:450mm, there are twelve forming hooks uniformly welded under the ring.

The gap is not more than 8mm.

8. The coating thickness is 70-80um, and it has the advantages of good acid and alkali resistance, moisture and heat resistance, and aging resistance.

9. Product structure principle: Through the hand handle to achieve vertical lifting column arm, lifting range 2.1-3.05m.

Easily rotate the handle to raise and lower the basketball stand without assistance.

The column is printed with a height scale, and the basketball stand can be used at different heights within the lifting range.
