Badminton stand TC-1080（200KG）

1.Cast iron mobile. The base is composed of three pieces of cast iron, and the middle is fixed by two steel wires.

The overall size is: telescopic (470-600) *360* 170MM, ×360 * 170MM,

weight 200KG, and the bottom is equipped with a roller, which is quiet, easy to use, and universal indoors and outdoors.

2. The column height is 1550MM, the use of ￠40 steel pipe,

the wall thickness is not less than 4MM, and a sliding roller is added to the top of the bracket to buffer the friction between the rope and the bracket,

and better control the length and height of the net.

The inner side is symmetrically equipped with a net hook of corresponding height, which is used to fix the badminton net.

3. The external surface adopts electrostatic powder spraying process, the adhesion of the coating layer should reach one level,

the hardness should reach 2H, there is a certain impact resistance, the surface has no wrinkles, no leakage, foaming, peeling

and obvious scratches and other defects. Rust removal must be taken before spraying to ensure that the coating is used outdoors for a long time.

Product coating formulations should not contain toxic elements.

4. The welding of each component shall be tight and firm,

 and there shall be no defects such as missing welding, virtual welding, cracks, etc.
