Youth elevator basketball stand TCJ-108

1.The extension arm of the basketball stand :0.75m-0.85m, (EVA protective case is optional)

2.The size of the ball frame base: length 1600mm x width 1000mm x height 410mm.

The use of 2.5mm thick sheet steel through the mold stamping molding, no weld,  All the corners are curved without edges.

The front end of the base has two universal wheels with brake function, and the rear end is equipped with two directional wheels.

3.The bottom of the column of the basket frame:180mmx180mm large rounded square pipe with a thickness of 3mm

4.The top of the column:150mmx150mm large rounded square pipe with a thickness of 3mm.

5.The lower extension arm of the basketball stand is composed of a set of 60mmx40mm rectangular tubes, which are partially welded;

6.The extension arm of the basketball stand is composed of a set of 40mmx40mm square tubes, which are welded together.

7.The back pull rod of the basketball stand adopts 2 sets of 40mmx40mm square tubes,

achieve the spiral lifting arm, lifting range in the height of 2.05m-3.05m.

8.The backboard is equipped with international high-strength safety tempered glass backboard specifications: 1200mmx900mm,

and the side of the backboard is covered with EVA protective rubber strip anti-aging does not fade.
